工业 100W 200W 300W
● 波形可编辑
● 长期工作稳定可靠
【应用】非金属材料加工
【参数】
|
关键参数 Key Parameters |
Unit |
指标 Specifications |
||||
|
型号 Model Number |
|
TDFL-100-CW |
TDFL-200-CW |
TDFL-300-CW |
||
|
光学指标 Optical characteristics |
||||||
|
工作模式 Operation Mode |
|
CW/QCW |
||||
|
偏振态 Polarization |
|
Random |
||||
|
中心波长 Central Wavelength |
nm |
1940±5.0 |
||||
|
光谱带宽 Emission Linewidth |
nm |
＜1 |
||||
|
最大输出功率 Max Output Power |
W |
100 |
200 |
300 |
||
|
调制频率 Pulse Repetition Rate |
kHz |
0.001~10 |
||||
|
功率调节范围 Power Tuning Range |
% |
10 ~100 |
||||
|
功率稳定性 Power Instability |
% |
≤ 3 |
||||
|
光束质量 Beam Quality |
M² |
≤ 1.5 |
||||
|
输出方式 Optical Output Termination |
|
SMA905 or QBH |
||||
|
输出光缆长度 Delivery Cable Length |
m |
3@SMA905，10@QBH |
||||
|
输出光纤芯径 Output Fiber Diameter |
μm |
25 |
||||
|
红光指示光功率 Red Guide Laser Power |
mW |
＞0.5 |
||||
|
通用指标 General Characteristics |
||||||
|
输入电压 Supply Voltage |
VAC |
180~265 |
||||
|
电功耗 Power Consumption |
W |
≤1600 |
||||
|
机箱尺寸 Dimensions (L*W*H) |
mm |
482.6*420*132.5 |
||||
|
重量 Weight |
kg |
~26 |
||||
|
冷却方式 Cooling Method |
|
Water-cooled |
||||
|
冷却水温 Water Temperature |
℃ |
21~23 |
||||
|
工作环境温度 Operating Temperature |
℃ |
-10 ~ +40 |
||||
|
储存温度 Storage Temperature |
℃ |
-20 ~ +70 |
||||
|
储存湿度 Relative Humidity |
% |
5 ~ +85 |
||||
